60,000# X 72" HERR VOSS UNCOILER (14587)

Herr Voss Uncoiler
Stock # 14587

-Material Width: 12" - 72"
-Weight Capacity: 60,000 lbs.
-Coil I.D.: 20" - 24" w/2" Thick Bolt on Pads for 28" I.D.
-Coil O.D. Capacity: 84"
-Pumpkin Tooth Mandrel
-Mandrel Face Width: 77"
-Powered Holddown Roll
-Hydraulic Expansion
-Wichita Water Cooled Brake
-Hydraulic Motor Threading Drive
-Sliding Base
-Passline: 57" from Floor to center of Mandrel
-Line Speed: 1000 Feet Per Minute
-Overall Size: 182" L x 87" W x 106" High
-Line Direction: Left to Right
-In Storage

**Temporary Specifications Subject to Revisions**
**PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**
**ALL SPECIFICATIONS ARE SUBJECT TO VERIFICATION**
