9 ” (228 mm) X 22” (559 mm) X 40” (1016 mm) HUNTER 4 HIGH ROLLING MILL (14533)

9” (228 mm) X 22” (559 mm) X 40” (1016 mm)
Stock # 14533

Type Mill: 4 High Rolling Mill
• Manufacturer: Hunter
• Thickness measurement Not Available
• Technical Specifications:
• Width min-max: 457 – 1016 mm.
• Entry Thickness: 0.38 mm Exit Max/Min Thickness: 0.3 / 2 x 0.007 mm.
• Line Speed: 730 mpm max
• Max Coil weight: 2000 kg.

• Mill Data:
• Work Roll Face: 1016 mm
• Work Rolls Diameter: 228 mm. Back Up Rolls diameter: 559 mm.
• 223.7 Kw Motor drive

• Uncoiler Data: Recoiler Data:
• Coil ID: 270/400 mm Coil ID: 270 mm.
• Coil OD: 914 mm Coil OD: 914 mm.
• Uncoiler 1 1 x 18.6 Kw Motor Drive 2 x 14.9 kw Motor Drive
• Uncoiler 2 1 x 18.6 Kw Motor DrivE

• Uninstalled in warehouse

• Control System Not Available
• Hydraulics, Controls & Electric Not Available
• Entry & exit coil rack
• Edge trimmer
**Temporary Specifications Subject to Revisions**
**PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**
**ALL SPECIFICATIONS ARE SUBJECT TO VERIFICATION**
