SARGEANT & WILBUR 12 STRAND COPPER WIRE ANNEALING FURNACE (14511)

MANUFACTURER: SARGEANT & WILBUR (USA)
STOCK # 14511

TYPE: 12 STRAND WIRE ANNEALING FURNACE FOR COPPER
MODEL NO: 0101274-12T
SERIAL NO. 9812-M4-F
NO. OF WIRE STRANDS: 12 (SEE NOTE BELOW)
TYPE OF WIRE: COPPER
MAX. TEMPERATURE: 1650 DEG.F (900 DEG. C)
POWER SOURCE: ELECTRIC
CAPACITY: 127 KW
ELECTRICS: 230 VOLTS, 3 PHASE, 60 HZ.

ATMOSPHERE GENERATOR
-MANUFACTURER: SARGEANT & WILBUR (USA)
-MODEL: GAD 750 E
-SERVICE: 230 VOLTS, 3 PHASE,60 HZ
- CAPACITY: 24 KW
-TEMP RATNG: 1750 DEG. F
-TEMPERATURE CONTROLS: HONEYWELL CORP (USA)

DIMENSIONS OF HEATING SECTION
-LENGTH: 284" (7213 MM)
-WIDTH: 54" (1371 MM)
-HEIGHT: 58" (1478 MM)

DIMENSIONS OF COOLING SECTION
-LENGTH 24 FT (7315 MM)
-WIDTH 23" (584 MM)
-HEIGHT 44" (1117 MM)

WIRE TAKE-UPS
-NO. OF STATIONS: 12
-DUAL WIRE TAKE-UP GUIDE WHEELS ON EACH DRUM
-SPEED CONTROLS
-HORIZONTAL TRAVERSE OF TAKE-UP DRUMS
NOTE: ONLY SIX TAKE-UPS WERE IN USE AT THE TIME OF SHUTDOWN
AND ARE COMPLETE. THE OTHER SIX MAY NEED PARTS.

**TEMPORARY SPECIFICATIONS SUBJECT TO REVISIONS**
**PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**
**ALL SPECIFICATIONS ARE SUBJECT TO BUYERS VERIFICATION**
