HUESTIS MODEL BMP-0750 WIRE BENDER (14315)

HUESTIS WIRE BENDER
Stock # 14315

Manufacturer:.................Huestis Machine Bristol, Rhode Island USA
Type Machine:.................Wire Bender
Model:........................BMP-075
Tube Diameter:................0.059 - 0.750" (1.5 - 19mm)
Max Wall thickness:...........0.060" (1.5mm)
Max Solid Diameter:...........0.375" (9.5mm)
Center Line Bend Radius:......2xD-4.00" (2xD-101.6mm)
Max Bend Angle:...............190 degrees
Min Straight Length:..........2xD***
***Min Straight Length for Clamping During Bend.
Max Orientation Angle:.......360 Degree
Standard Mandrel Length:.....78"
Air Requirements:.............80 - 100 psi
Machine Weight:...............2,000 lbs

**Temporary Specifications Subject to Revision**
**PRICE QUOTED AS IS WHERE IS SUBJECT TO PRIOR SALE**
**ALL SPECIFICATIONS ARE SUBJECT TO VERIFICATION**
